Larger equal tees manufactured from pipe can offer an alternative to moulded tees. Fabricated equal tees as per the POP006 Guidelines should be derated by 50% or rated to .5 of the pipes’ original class. This means that a tree manufactured from SDR11 PN16 or SDR 17, PN10 pipe would be rated conservatively at 8bar …
Fabricated true Ys are standardly manufactured so the two legs are at 90-degrees in a capital “Y” shape. True Ys are used in many industrial applications, such as pump stations for adding an auxiliary backup pump, dewatering suction, and delivery lines. They are also used in dam transfer, dust suppression reticulation systems, and product bin …
Fabricated Junctions are widely used for gravity systems, or high wear entries and discharges, such as tailings distribution and waste transfer. They are also very useful entry points for cleaning pigs or pig entries. We recommend moulded junctions where possible – these are available in sizes up to 315mm. For larger sizes we manufacture in …
The best performing bend are long radius bends. In Australian piping these are known as sweep bends and 3D bends. The gradual curve in sweep bends minimise the disruption of fluids while changing directions. Sweep bends standardly are much bigger dimensionally, which in some situations may have been a limitation in the past. Advanced Piping …
At Advanced Piping 45-degree seamless bends, also known as sweeps or radius bends, are manufactured by bending pipe. Sweep bends are the best performing bend available and will be beneficial in high wear or high-pressure applications. In some situations, it may be beneficial use two 45-degree bends instead of one 90-degree bend. This option can …
At Advanced Piping, we manufacture high-quality forged reducing tees in sizes ranging from 200mm to 1200mm. These, also known as pull tees, are made by drawing a spigot from the parent pipe wall, creating a smooth, consistent transition between the mainline pipe and the branch. This manufacturing process offers several benefits over traditional saddle fusion …
Advanced Piping’s 45-degree SDR11 segmented bends are standardly CNC manufactured in two 22.5-degree segments. If a full pressure rating is required we also offer these fabricated at 3 x 15-degree segments, achieving a full pressure class conformance to align with the POP006 PIPA Guidelines – the most recently updated guide, superseding previous PIPA Guidelines: POP004 …
Advanced Piping’s 45-degree SDR11 and SDr17 segmented bends are standard CNC manufactured in two 22.5-degree segments. If a full pressure rating is required we also offer these fabricated at 3 x 15-degree segments, achieving a full pressure class conformance to align with the POP006 PIPA Guidelines – the most recently updated guide, superseding previous PIPA …
